Jaw frame

Jaw frame 25T

Jaw frame 25T for DN500 telescope pipe

Specifications:

Product code:

3366139/40-N

Warranty:

2 Years

Product category:

Normal

Market:

Estonia, Finland, Latvia, Norway, Sweden

Product type:

Set

Locking mechanism:

————

EN load class:

C250

Weight:

91 kg

Width:

600 mm

Max height:

270 mm

Seating depth:

————

mm

Lenght:

585 mm

Frame opening:

420 mm

Pipe fit outer diameter:

————

mM

Fit together:

————

Product set:

————

Material marks:

Ductile EN-GJS-500/7
