Manhole cover
900 round frame and blind cover with district heating logo

900-series set 3366137/8-KL consists of a floating, round frame 3366137-N and a round blind cover 3366138-KL. The set is designed for Nordic conditions, in accordance with standard EN 124-2:2015, manufactured from ductile iron EN-GJS-500/7 and is classified under Load Class D400.

Typical application is district heating.

Specifications:
Product code:
3366137/8-KL
Warranty:
2
Years
Product category:
District heating, Normal
Market:
Estonia, Finland, Latvia, Norway, Sweden
Product type:
Set
EN load class:
D400
Material marks:
Ductile EN-GJS-500/7
measurements:
Weight:
203
kg
Max height:
135
mm
diameter:
1240
mm
Seating depth:
50
mm
Frame opening:
850
mm
