Manhole cover
500 Optimized frame with blind cover
500-series Optimized set 3366148/9-N consists of a floating, round frame 3366148-N and a lockable, round blind cover 3366149-N. The set is designed for Nordic conditions, in accordance with standard EN 124-2:2015, manufactured from ductile iron EN-GJS-500/7 and is classified under Load Class D400.
Cover can be opened using a crowbar. The set assembly is compatible with DN500 mm telescope pipe
Typical applications are inner streets, car parks, pedestrian zones.
Specifications:
Product code:
3366148/9-N
Warranty:
1
Years
Product category:
Optimized
Market:
Estonia, Finland, Latvia, Norway, Sweden
Product type:
Set
Locking mechanism:
Spring locks
EN load class:
D400
Material marks:
Ductile EN-GJS-500/7
measurements:
Weight:
32
kg
Max height:
85
mm
diameter:
640
mm
Seating depth:
20
mm
Frame opening:
456
mm
